eSUN PA-CF — Carbon-Fiber Nylon Filament
PA-CF · Matte
Colors
Select printer
Where to Buy
AliExpress
$35,85
Реклама · erid: 2SDnjcoSatrSpecifications
Nozzle temperature260–290 °C
Bed temperature60–90 °C
EnclosureYes
Hardened nozzleYes
Drying before printingYes
Density1.18 g/cm³
Description
eSUN PA-CF is carbon-fiber reinforced nylon. The carbon adds stiffness, heat resistance and dimensional stability to an already tough nylon. It's one of the most engineering-grade consumer filaments: parts are stiff, impact-resistant and hold high temperatures.
Print Settings
- Nozzle temperature: 260–290 °C
- Bed temperature: 60–90 °C
- Cooling fan: off or minimal
- Nozzle: hardened, 0.4 mm+
- Drying: 80 °C for about 8 hours before printing
Two demands: carbon fiber is abrasive (hardened nozzle required) and nylon is very hygroscopic (thorough drying at 80 °C required). The 260–290 °C nozzle temp needs an all-metal hotend.
Great for the most demanding engineering parts: brackets, housings, tooling and automotive components that run warm. Needs an enclosure, a hardened nozzle and dry filament.
FAQ
An all-metal hotend with a hardened nozzle. The 260–290 °C print temp is too hot for PTFE in the heat zone, and carbon fiber wears out a brass nozzle.
